RF IDeas pcProx Plus Reader RDR-80581AKU-C06 WAVE ID®

Overview

The RF IDeas pcProx Plus is a cutting-edge card reader that combines proximity and contactless technologies into one reader. It is a desktop reader that is capable of reading both 125 kHz proximity cards and 13.56 MHz contactless cards. This reader eliminates the need for manual entry and provides error-free identification and security throughout the workplace. The pcProx Plus allows users to use their building access card or any 125 kHz or 13.56 MHz tags/labels for other forms of identification.

The plug-n-play reader comes with flash memory, allowing users to quickly configure the output to meet their needs. With its dual-frequency multi-technology, the pcProx Plus is highly configurable and capable of simultaneously handling any two of the available technologies.

As a card and badge enroller or reader, it emulates a keyboard to keystroke the card’s data to the cursor’s location in an application. The reader can be configured to add keystrokes and commands before or after the card’s data.

The pcProx Plus reader can be used as a stand-alone unit, or can be seamlessly integrated with other software applications using the optional Software Developer Kit (SDK). As an integrated reader, it has the ability to work with a multitude of applications.

Applications

• PC/LAN Access Control
• Application Log-On
• Employee Identification
• PLC and Embedded Controllers
• M
• OEM
• Time and Attendance
• Meeting Attendance, Visitor Management
• Hoteling
• Secure Printing
• Point of Sale
• Dispensing
• Mobile
• Physical Access

Features

Easy interface

USB models connect directly to a USB port and can be configured to send data as keystroking, non-keystroking or serial ASCII.

RS-232 models connect to a serial port and send data as ASCII. Ethernet models connect through an RJ45 connection and are sent data as either ASCII or E/IP.

Note: To utilize PoE and E/IP features with some models, a C-6200 adapter may be required

Compatibility

Compatible with Windows CE®/2000®/XP®/ Vista®/7®, Macintosh®, Solaris™, ThinManager® thin clients, and Linux. (Free configuration software required on Windows® operating system.)

Improves accuracy of information and productivity

Eliminates errors associated with individual identification.

Versatile mounting options

Featuring an articulated cable, the standard housing reader can easily be mounted on kiosks, monitors, time clocks, and more.

*Also available in a wall mount design.

Meets Medical/Healthcare HIPAA Requirements

When used as a log-on reader

Meets CJIS Compliance Requirements

All pcProx readers are CJIS compliant and designed to keep law enforcement and criminal justice organizations current with compliance requirements

Meets IP67 Compliance Requirements

pcProx Wall Mount Only—When the IP67 Wall Mount reader is installed in accordance with the IP67 Wall Mount instructional guide

pcProx® 125 kHz Supported Cards—Partial List

AWID
Cardax*
CASI-RUSCO®
Deister*
DIGITAG
EM 410x
Farpointe Data
GProx™ II*
HID® Prox
HiTag 1, S & 2
IDTECK
Indala® (Motorola)
ioProx™ (Kantech)
Keri NXT
Keri* Nexwatch (Honeywell)
Pyramid
Radio Key®
ReadyKey Pro*

pcProx® 13.56 MHz Supported Cards—Partial List

iCLASS® SE™
iCLASS ID
iCLASS CSN
NFC CSN Type 2/4
Advant CSN (Legic)
I-Code CSN
Tag-It CSN
eTag CSN
I-tag CSN
ISO 14443A CSN1
ISO 15693 CSN
MIFARE CSN
MIFARE Ultralight CSN
my-d CSN
DESFire CSN
